TMC2208-LA Trinamic Motion Control GmbH
Same model may have multiple batches, images only for reference.

TMC2208-LA

Part No TMC2208-LA
Manufacturer Trinamic Motion Control GmbH
Catalog PMIC - Motor Drivers, Controllers
Description STEPPER MOTOR DRIVER IC, STEP/DI
Datasheet
TMC2208-LA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Motor Drivers, Controllers
Mfr Trinamic Motion Control GmbH
Series StealthChop™
Package Tray
Product Status Active
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (2)
Interface SPI, Step/Direction, UART
Technology Power MOSFET
Step Resolution 1 ~ 1/256
Applications General Purpose
Current - Output 1.2A
Voltage - Supply 5.5V ~ 36V
Voltage - Load 5.5V ~ 36V
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 28-VFQFN Exposed Pad
Supplier Device Package 28-QFN (5x5)
Base Product Number TMC2208
Standard Package 490 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 840660-TMC2208-LA
Ultra Librarian 3D Model Ultra Librarian TMC2208-LA CAD Model

Description

The TMC2208-LA is a fully integrated motor driver IC designed for general-purpose applications.

  • Output Configuration: Half-bridge
  • Motor Types: Bipolar stepper motors and brushed DC motors
  • Voltage Range: 5.5V to 36V
  • Technology: Power MOSFET
  • Current Output: 1.2A
  • Step Resolutions: 1 to 1/256
  • Control Interfaces: SPI, Step/Direction, or UART
  • Package: 28-VFQFN
  • Mounting: Surface mount
  • Operating Temperature: -40°C to 125°C
  • Compliance: ECCN and MSL standards
  • Product Status: Active
  • Manufacturer: Trinamic Motion Control GmbH
