TLP291-4(GB-TP,E) Toshiba Semiconductor and Storage TLP291-4(GB-TP,E) real image 2 TLP291-4(GB-TP,E) Real Image1 TLP291-4(GB-TP,E) Real Image2 TLP291-4(GB-TP,E) Real Image3 TLP291-4(GB-TP,E) Real Image4 TLP291-4(GB-TP,E) Real Image5 TLP291-4(GB-TP,E) Real Image6 TLP291-4(GB-TP,E) Real Image7 TLP291-4(GB-TP,E) Real Image8 TLP291-4(GB-TP,E) Real Image9 TLP291-4(GB-TP,E) Real Image10 TLP291-4(GB-TP,E) real image TLP291-4(GB-TP,E) label picture
Same model may have multiple batches, images only for reference.
TLP291-4(GB-TP,E) Toshiba Semiconductor and Storage TLP291-4(GB-TP,E) real image 2 TLP291-4(GB-TP,E) Real Image1 TLP291-4(GB-TP,E) Real Image2 TLP291-4(GB-TP,E) Real Image3 TLP291-4(GB-TP,E) Real Image4 TLP291-4(GB-TP,E) Real Image5 TLP291-4(GB-TP,E) Real Image6 TLP291-4(GB-TP,E) Real Image7 TLP291-4(GB-TP,E) Real Image8 TLP291-4(GB-TP,E) Real Image9 TLP291-4(GB-TP,E) Real Image10 TLP291-4(GB-TP,E) real image TLP291-4(GB-TP,E) label picture
TLP291-4(GB-TP,E) Toshiba Semiconductor and Storage TLP291-4(GB-TP,E) real image 2 TLP291-4(GB-TP,E) Real Image1 TLP291-4(GB-TP,E) Real Image2 TLP291-4(GB-TP,E) Real Image3 TLP291-4(GB-TP,E) Real Image4 TLP291-4(GB-TP,E) Real Image5 TLP291-4(GB-TP,E) Real Image6 TLP291-4(GB-TP,E) Real Image7 TLP291-4(GB-TP,E) Real Image8 TLP291-4(GB-TP,E) Real Image9 TLP291-4(GB-TP,E) Real Image10 TLP291-4(GB-TP,E) real image TLP291-4(GB-TP,E) label picture
Same model may have multiple batches, images only for reference.

TLP291-4(GB-TP,E)

Part No TLP291-4(GB-TP,E)
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLTR 2.5KV 4CH TRANS 16-SO
Datasheet
TLP291-4(GB-TP,E) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 100% @ 5mA
Maximum DC Current Transfer Ratio 400% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 16-SO
Win Source Part Number 032833-TLP291-4(GB-TP,E)
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TLP291-4(GB-TP,E) CAD Model

Description

The Toshiba Semiconductor and Storage 032833-TLP291-4(GB-TP,E) is a surface mount device (SMD) that is perfect for use in isolators.

  • Output Type: Transistor
  • Input Type: DC
  • Number of Channels: 4
  • Vce Saturation (max): 400mV
  • Isolation Voltage: 2500Vrms
  • Operating Temperature Range: -55°C to 110°C
  • Case/Package: 16-SO
  • Minimum DC Current Transfer Ratio: 100% @ 5mA
  • Maximum DC Current Transfer Ratio: 400% @ 5mA
  • Switching Turn-On Time: 3μs
  • Switching Turn-Off Time: 3μs
  • Rise Time: 2μs
  • Fall Time: 3μs
  • Maximum Output Voltage: 80V
  • Channel Output Current: 50mA
  • Continuous Forward Current-Max: 50mA
  • Supply and Demand Status: Limited
