TLP2309 Toshiba Semiconductor and Storage TLP2309 Real Image1 TLP2309 Real Image2
Same model may have multiple batches, images only for reference.
TLP2309 Toshiba Semiconductor and Storage TLP2309 Real Image1 TLP2309 Real Image2
TLP2309 Toshiba Semiconductor and Storage TLP2309 Real Image1 TLP2309 Real Image2
Same model may have multiple batches, images only for reference.

TLP2309

Part No TLP2309
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV TRANS 6-SO 5 LEAD
Datasheet
TLP2309 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 15% @ 16mA
Switching Turn-On and Turn-Off Time 1μs, 1μs (Max)
Input Type DC
Output Type Transistor
Maximum Output Voltage 20V
Channel Output Current 8mA
Forward Voltage 1.55V
Continuous forward current- Max 25mA
Temperature Range - Operating -40°C to 110°C
Mounting SMD (SMT)
Case / Package 6-SO, 5 Lead
Win Source Part Number 213035-TLP2309
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TLP2309 CAD Model

Description

The Toshiba Semiconductor and Storage TLP2309 is an active electronic component that is designed for use in high-performance isolation applications.

  • Use: industrial automation, motor control, and power supply circuits
