TLP183(GR-TPL,E

Name: TLP183(GR-TPL,E
Brand: Toshiba Semiconductor and Storage
SKU: 525832
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP183(GR-TPL,E
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOISO 3.75KV TRANS 6-SO 4 LEAD
Datasheet	TLP183(GR-TPL,E Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel - TR
Status	Active
Number of Channels	1
Isolation Voltage	3750Vrms
Minimum DC Current Transfer Ratio	100% @ 5mA
Maximum DC Current Transfer Ratio	300% @ 5mA
Switching Turn-On and Turn-Off Time	3μs, 3μs
Rise and Fall Time	2μs, 3μs
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	80V
Channel Output Current	50mA
Forward Voltage	1.25V
Continuous forward current- Max	50mA
Vce Saturation (Max)	300mV
Temperature Range - Operating	-55°C to 125°C
Mounting	SMD (SMT)
Case / Package	6-SO, 4 Lead
Win Source Part Number	1108848-TLP183(GR-TPL,E
Popularity	Medium
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian TLP183(GR-TPL,E CAD Model

Alternative Products

Description

The TLP183(GR-TPL,E) is a Toshiba Semiconductor and Storage electronic component.

Type: Transistor Output
Forward Voltage: 1.25V
Isolation Voltage: 3750Vrms
Minimum DC Current Transfer Ratio: 100% @ 5mA
Maximum DC Current Transfer Ratio: 300% @ 5mA
Switching Turn-On Time: 3μs
Switching Turn-Off Time: 3μs
Rise Time: 2μs
Fall Time: 3μs
Popularity: Medium
Supply and Demand Status: Sufficient
