TLP131(GB-TPL,F) Toshiba Semiconductor and Storage TLP131(GB-TPL,F) real image TLP131(GB-TPL,F) real image7444
Same model may have multiple batches, images only for reference.
TLP131(GB-TPL,F) Toshiba Semiconductor and Storage TLP131(GB-TPL,F) real image TLP131(GB-TPL,F) real image7444
TLP131(GB-TPL,F) Toshiba Semiconductor and Storage TLP131(GB-TPL,F) real image TLP131(GB-TPL,F) real image7444
Same model may have multiple batches, images only for reference.

TLP131(GB-TPL,F)

Part No TLP131(GB-TPL,F)
Manufacturer Toshiba Semiconductor and Storage
Catalog HOT - SALES and EOL Components
Description Optocoupler DC-IN 1-CH Transistor With Base DC-OUT 5-Pin MFSOP T/R / OPTOCOUPLER TRANS
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Part Status Last Time Buy
Voltage - Isolation 3750Vrms
Current Transfer Ratio (Minimum) 100% at 5mA
Current Transfer Ratio (Maximum) 600% at 5mA
Turn On / Turn Off Time 3μs, 3μs
Rise / Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor with Base
Maximum Output Voltage 80V
Current - Output / Channel 50mA
Voltage - Forward (Vf) 1.15V
Current - DC Forward (If) (Maximum) 50mA
Vce Saturation (Maximum) 400mV
Temperature Range - Operating -55°C ~ 100°C
Mounting Style SMD
Manufacturer Package 6-SOIC , 5 Leads
Supplier Device Package 6-MFSOP, 5 Lead
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Win Source Part Number 092626-TLP131(GB-TPL,F)
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TLP131
Introduction Date May 15, 2001
ECCN EAR99
Country of Origin Japan
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian TLP131(GB-TPL,F) CAD Model

Description

The TLP131 is a transistor with base output type optocoupler manufactured by Toshiba Semiconductor and Storage, featuring a current output/channel of 50mA and voltage isolation of 3750Vrms.

  • Operating Temperature: -55°C to 100°C
  • Suitable Applications: industrial and consumer electronics applications
  • Use: commonly used as an isolator
  • Popularity: high popularity rating
  • Supply and demand: in balance
  • Manufacturer Package: 6-SOIC with 5 leads
  • Manufacturer Pack Quantity: 3,000
  • Status: obsolete, estimated EOL date
  • Alternative Parts: ACPL-M51L-500E, PS8703-F4, PS8703, and PS8703-F3
