The TC9560XBG is a Gigabit Ethernet bridge IC manufactured by Toshiba Semiconductor and Storage. This IC is designed to facilitate high-speed data transfer between different interfaces, primarily targeting automotive and industrial applications requiring robust and reliable network connectivity. It serves as a bridge to connect devices using various communication protocols to a Gigabit Ethernet network.

Applications

• Automotive Ethernet: Used in advanced driver-assistance systems (ADAS), in-vehicle infotainment (IVI) systems, and automotive gateways.
• Industrial Automation: Integrated into industrial PCs, programmable logic controllers (PLCs), and network switches for factory automation.
• Networking Equipment: Employed in network interface cards (NICs), routers, and switches for high-speed data communication.

Features

• Gigabit Ethernet Support: Supports Gigabit Ethernet (1000BASE-T) for high-speed data transmission.
• AVB/TSN Support: Supports Audio Video Bridging (AVB) and Time-Sensitive Networking (TSN) standards for real-time data delivery.
• PCI Express (PCIe) Interface: Features a PCIe interface for high-bandwidth connectivity to host processors.
• Switching Functionality: Includes integrated switching functionality to manage network traffic.
• Quality of Service (QoS): Implements QoS mechanisms to prioritize critical data streams.
• Energy-Efficient Ethernet (EEE): Supports EEE standards for reduced power consumption.

Benefits

• High-Speed Data Transfer: Enables high-speed data transfer for demanding applications.
• Real-Time Communication: Supports real-time communication with AVB/TSN standards.
• Robust Network Connectivity: Provides robust network connectivity for reliable data transmission.
• Reduced System Latency: Minimizes system latency for responsive performance.
• Energy Efficiency: Offers energy-efficient operation for reduced power consumption.

Additional Details

The TC9560XBG operates on a 3.3V power supply and is available in a BGA (Ball Grid Array) package. It supports a wide range of operating temperatures, making it suitable for harsh industrial and automotive environments. The device integrates advanced security features to protect against unauthorized access and data breaches. The TC9560XBG is a critical component for enabling advanced networking capabilities in automotive and industrial applications.
