The U60D20C is a Schottky Barrier Rectifier manufactured by Thinki Semiconductor Co., Ltd. This diode is designed for high-frequency rectification applications requiring low forward voltage drop and fast switching speeds.

Applications

• Switching power supplies
• DC-DC converters
• Freewheeling diodes
• Reverse polarity protection
• High-frequency inverters

Features

• Low forward voltage drop
• High surge current capability
• High switching speed
• High reliability
• Lead-free finish

Benefits

• Improved efficiency in power conversion circuits
• Enhanced system robustness with high surge current handling
• Reduced switching losses at high frequencies
• Increased product lifespan due to reliable performance
• Environmentally friendly due to lead-free construction

Additional Details

The U60D20C features a repetitive peak reverse voltage (VRRM) of 200V and a forward current (IF) of 60A. It is designed to minimize power losses in high-frequency applications. The low forward voltage drop reduces heat generation, improving overall system efficiency. It is commonly available in a TO-247 package. The Schottky Barrier design ensures very fast reverse recovery times, making it ideal for applications where rapid switching is required. The device's specifications provide detailed information on its electrical characteristics, including reverse leakage current and thermal resistance.
