FDC6323L

Part No FDC6323L
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Power Distribution Switches, Load Drivers
Description Power Switch Hi Side 1-OUT 1A 0.3Ohm 6-Pin TSOT-23 T/R / IC LOAD SWITCH INT 8VIN SSOT-6
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type P-Channel
Voltage - Load 3 V to 8 V
Supply Voltage - Operating 1.5 V to 8 V
Current - Output (Max) 1.5A
Input Type Non-Inverting
Temperature Range - Operating -55°C to 150°C (TJ)
Case / Package SuperSOT-6
Win Source Part Number 001140-FDC6323L
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management
Quantity per package 3k pcs
Family Name FDC6323L
Introduction Date March 31, 1999
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian FDC6323L CAD Model

Description

FDC6323L

The FDC6323L is a dual MOSFET designed specifically for modern electronic requirements, prioritizing both performance and cost-effectiveness. Known for its versatility and low power consumption, it serves well in a variety of applications.

  • Applications:
    • LED driving systems
    • Telecommunications equipment
    • Portable devices
  • Features and Benefits:
    • High Power Performance: Suitable for applications requiring robust power handling.
    • Cost-Efficient: Balances performance with affordability for budget-conscious projects.
    • Environment-Friendly: Complies with RoHS standards for safer electronics.

The FDC6323L represents a reliable solution for designers in need of high-performance MOSFETs with an eco-friendly design commitment.
