Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Driven Configuration High-Side or Low-Side
Channel Type Single
Number of Drivers 1
Gate Type IGBT, N-Channel MOSFET
Supply Voltage - Operating 10 V to 32 V
Logic Voltage - VIL, VIH 1.2V, 2.2V
Current - Peak Output (Source, Sink) 2.5A, 5A
Input Type Non-Inverting
Rise and Fall Time 15ns, 7ns
Temperature Range - Operating -40°C to 140°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-6
Win Source Part Number 081867-UCC27531DBVR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian UCC27531DBVR CAD Model

Description

Overview of Texas Instruments UCC27531DBVR

The UCC27531DBVR from Texas Instruments is a robust gate driver IC designed to deliver high peak current output of up to 2.5A, suitable for driving power MOSFETs, IGBTs, and other types of power transistors. This gate driver operates with a supply voltage range from 4.5V to 18V, making it versatile for various applications and ensuring compatibility with a wide range of control circuits and power stages.

Key Features

  • High-Current Drive Capability: With a peak output current of +/-2.5A, the UCC27531DBVR can effectively switch power transistors at high speeds, reducing switching losses and improving overall efficiency.
  • Wide Supply Voltage Range: The device operates over a supply voltage range of 4.5V to 18V, accommodating various circuit designs and ensuring stable operation under fluctuating supply conditions.
  • Split Output Configuration: It offers a split output that allows the designer to independently control the rise and fall times, optimizing switching performance for specific applications.
  • Robust Design: The UCC27531DBVR includes negative voltage handling capability on the input and with UVLO (Under Voltage Lock Out) feature, it ensures reliable operation even during undervoltage scenarios.
  • Industry-Standard Package: Housed in an SOT-23-6 package, it is compact and compatible with standard PCB manufacturing processes, allowing for easy integration into a variety of designs.

Applications

The versatility and performance of the UCC27531DBVR make it an excellent choice for a broad range of applications, including:

  • Switch Mode Power Supplies (SMPS)
  • Motor Control Circuits
  • DC-DC Converters
  • Power Inverters
  • Class-D Audio Amplifiers
  • LED Lighting Systems

With its ability to drive large capacitive loads with minimal delay and overshoot, the UCC27531DBVR is ideal for designers looking to improve the performance and reliability of their power management systems. Its robust construction and comprehensive feature set ensure that it can meet the stringent requirements of modern electronic designs.

For detailed technical specifications, application notes, and support resources, the Texas Instruments website provides extensive documentation to assist designers in implementing the UCC27531DBVR into their projects.
