Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Driven Configuration Low-Side
Channel Type Independent
Number of Drivers 2
Gate Type N-Channel, P-Channel MOSFET
Supply Voltage - Operating 4.5 V to 15 V
Logic Voltage - VIL, VIH 1V, 2V
Current - Peak Output (Source, Sink) 4A, 4A
Input Type Non-Inverting
Rise and Fall Time 20ns, 15ns
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 035758-UCC27324DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian UCC27324DR CAD Model

Description

Product Overview: UCC27324DR by Texas Instruments

The UCC27324DR is a high-speed, dual-channel power MOSFET driver designed and manufactured by Texas Instruments. This integrated circuit is specifically engineered to deliver robust and efficient performance for driving MOSFETs and IGBTs. The device is housed in an 8-pin SOIC package, making it suitable for space-constrained applications.

Key Features

  • High Current Drive Capability: The UCC27324DR can source up to 4A and sink up to 4A, providing the high current necessary to rapidly charge and discharge the gate capacitance of power MOSFETs, thus enabling fast switching transitions.
  • Independent Channels: It features two independent driver channels that can be configured for dual low-side, dual high-side, or high-side/low-side applications. This flexibility allows the device to be used in a variety of power management configurations.
  • Wide Supply Voltage Range: The device operates over a wide supply voltage range from 4.5V to 15V, accommodating various application requirements and ensuring compatibility with a broad range of control logic levels.
  • Efficient Power Management: The UCC27324DR incorporates matched propagation delays between channels and low supply current, which enhances power efficiency and reduces operational costs.
  • Robust Design: It is designed with features such as cross-conduction prevention logic, under-voltage lockout protection, and thermal shutdown, which contribute to system reliability and longevity.

Applications

The versatility of the UCC27324DR makes it an ideal choice for a wide range of applications, including but not limited to switch-mode power supplies, DC-DC converters, motor controllers, and Class-D audio amplifiers. Its ability to drive high-capacitance loads with minimal delay and power loss makes it a go-to solution for designers seeking to optimize power efficiency and performance.

Conclusion

In summary, the UCC27324DR from Texas Instruments stands out as a high-performance, dual-channel MOSFET driver that offers the reliability and flexibility needed for advanced power management solutions. Its high current drive capability, coupled with its wide voltage range and robust protective features, make it a valuable component for any power electronics system designer.
