Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Translator Type Voltage Level
Channel Type Bidirectional
Number of Circuits 1
Channels per Circuit 8
Voltage - VCCA 1.2V to 3.6V
Voltage - VCCB 1.65V to 5.5V
Output Type Open Drain, Push-Pull
Data Rate 60Mbps
Temperature Range - Operating -40°C to 85°C (TA)
Features Auto-Direction Sensing
Mounting SMD (SMT)
Case / Package 20-TSSOP
Win Source Part Number 035493-TXS0108EPWR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Audio, Consumer Electronics, Computers & Computer Peripherals
Family Name TXS0108
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TXS0108EPWR CAD Model

Description

The TXS0108EPWR is a state-of-the-art, 8-bit bidirectional voltage-level translator designed and manufactured by Texas Instruments. This device is part of TI's extensive range of logic and voltage translation solutions, engineered to bridge the gap between devices operating at different voltage levels. The TXS0108EPWR is particularly useful in applications where communication between incompatible I/O voltages is necessary.

Key Features

  • Voltage Level Translation: Capable of translating between two different voltage domains, ranging from 1.2V to 3.6V on the A side and 1.65V to 5.5V on the B side, the TXS0108EPWR ensures seamless integration of peripherals with different voltage requirements.
  • Auto-Direction Sensing: The device automatically senses the direction of data flow without the need for a direction control signal, simplifying circuit design and reducing control pin requirements.
  • High-Speed Operation: It supports high-speed signal propagation with a maximum data rate of up to 60 Mbps, making it suitable for fast communication protocols.
  • Low Standby Current: The TXS0108EPWR is optimized for low-power operation, with a typical standby current of only 10 uA, contributing to energy-efficient designs.
  • ESD Protection: The device includes robust electrostatic discharge (ESD) protection circuitry, which helps to prevent damage from static electricity and enhances system reliability.

Applications

The versatile nature of the TXS0108EPWR makes it an ideal choice for a wide range of applications, including but not limited to:

  • Multivoltage digital system interfaces
  • Data communication between devices with different voltage levels
  • Interface conversion for sensors, processors, or memory devices
  • Mobile phones, PDAs, and other portable consumer electronics

Package and Quality

The TXS0108EPWR is offered in a compact TSSOP (Thin Shrink Small Outline Package) with 20 pins, which is ideal for space-constrained applications. Texas Instruments' commitment to quality ensures that this voltage-level translator meets the highest industry standards for performance and reliability.

For designers and engineers looking to create seamless, multi-voltage interfaces in their digital systems, the TXS0108EPWR by Texas Instruments offers a flexible and robust solution.
