The TXB0104GXUR is a versatile, 4-bit bidirectional voltage-level translator from Texas Instruments designed for mixed-voltage digital systems. It facilitates communication between devices operating at different voltage levels, ranging from 1.2V to 3.6V on the A side (VCCA) and 1.65V to 5.5V on the B side (VCCB), making it an essential component for multi-voltage digital system designs.

Key Features

• Bi-Directional Translation: The TXB0104GXUR supports bidirectional voltage translation without the need for a direction control signal, simplifying the design and saving valuable board space.
• Auto-Direction Sensing: It automatically senses and adjusts to the direction of data flow, providing a seamless interface between different voltage domains.
• Low Power Consumption: Designed with power efficiency in mind, this voltage translator has a low standby current, which is ideal for battery-operated applications.
• High-Speed Operation: It is capable of supporting up to 100 Mbps (mega-bits per second) push-pull applications, ensuring high-speed data transmission for demanding applications.
• Robust ESD Protection: The device includes 15 kV Human Body Model (HBM) ESD protection on all pins, safeguarding the device from electrostatic discharges during handling and operation.

Applications

The TXB0104GXUR is suitable for a wide range of applications, including but not limited to:

• Mobile Phones
• PDAs and Handheld Devices
• Laptops and Notebooks
• Portable Media Players
• Data Communication Systems

Package and Quality

Offered in a compact X2SON package, the TXB0104GXUR is designed to occupy minimal board space while providing maximum functionality. Texas Instruments is committed to delivering high-quality products, and this device is no exception, meeting stringent industry standards for performance and reliability.
