The TUSB522PRGER is a high-performance, adaptive equalization USB 3.2 Gen 1 dual-channel redriver from Texas Instruments (TI). This advanced integrated circuit is designed to enhance signal quality by performing receive equalization on the deteriorated input signal, followed by transmit de-emphasis, maximizing system link performance. It is an ideal solution for applications where signal integrity may be compromised due to long PCB traces, cables, or other challenging transmission media.

Key Features

• Dual-Channel Redriver: The TUSB522PRGER features two bidirectional channels, supporting both downstream and upstream traffic, which is essential for versatile USB 3.2 Gen 1 applications.
• Adaptive Equalization: This product incorporates adaptive equalization technology, which automatically adjusts to the optimal level to compensate for inter-symbol interference (ISI) and to restore signal integrity.
• Transmit De-Emphasis: The device provides programmable transmit de-emphasis, allowing for the reduction of transmission errors by compensating for channel losses.
• Low Power Consumption: The TUSB522PRGER is designed with power efficiency in mind, maintaining low power consumption to meet the needs of power-sensitive applications.
• Small Form Factor: Packaged in a small, 3 mm x 4.5 mm, 24-pin QFN package, the TUSB522PRGER saves valuable board space, making it suitable for compact systems.

Applications

The TUSB522PRGER is suitable for a wide range of applications, including but not limited to:

• Desktop and Laptop Computers
• Docking Stations
• Display Applications
• USB Hubs and Peripherals
• Consumer Electronics

Technical Specifications

The device operates over a wide temperature range and is compatible with USB 3.2 Gen 1 signaling rates up to 5 Gbps. It is also backward compatible with USB 2.0 and 1.1 standards, ensuring broad device interoperability. The TUSB522PRGER includes an I2C interface for device configuration, enabling customized performance tuning to match specific system requirements.

For designers and engineers looking to enhance USB signal quality in their projects, the TUSB522PRGER from Texas Instruments offers a reliable and efficient solution with its advanced features and compact design.
