The TPS65982DAZBHR from Texas Instruments is a highly integrated and configurable solution designed for USB Type-C and USB Power Delivery (PD) applications. This advanced controller integrates power switches and manages the Power Delivery communication required for negotiating USB Type-C current levels, modes, and orientations.

Key Features

• USB Type-C and Power Delivery (PD) Protocol: The TPS65982DAZBHR supports the full USB PD 3.0 protocol, enabling higher power capabilities and a range of flexible power delivery options.
• Integrated Power Path: This device includes integrated NMOS power switches for both source and sink power paths, providing efficient power management and reducing external component count.
• Configurable Ports: The controller supports multiple USB Type-C ports with role swapping capabilities, making it suitable for a variety of applications including docks, monitors, and power adapters.
• Alternate Mode Support: It offers support for alternate modes such as DisplayPort and Thunderbolt, allowing the USB Type-C connector to carry non-USB signals.
• Dead Battery Provision: The TPS65982DAZBHR supports the dead battery scenario, enabling USB PD communication even when the battery is not charged.

Applications

• Notebooks, Tablets, and Mobile Devices
• USB Type-C Power Adapters and Chargers
• USB Type-C Docking Stations
• Monitors and Peripherals with USB Type-C

Technical Specifications

The TPS65982DAZBHR operates over a wide supply voltage range and offers a comprehensive set of protections including over-current, over-voltage, under-voltage lockout, and thermal protection to ensure reliable operation under various conditions. The device comes in a 6.00 mm x 6.00 mm, 76-pin VQFN package, optimizing the space on the PCB and making it ideal for compact designs.

As a product of Texas Instruments, a leader in semiconductor solutions, the TPS65982DAZBHR is backed by robust technical support and comprehensive documentation, ensuring ease of integration into your design projects.
