Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel
Function Step-Down
Topology Buck
Output Type Adjustable
Voltage - Input (Minimum) 2.5V
Voltage - Input (Maximum) 5.5V
Min/Fixed Output Voltage 0.8V
Maximum Output Voltage 5.5V
Output Current 4A
Switching Frequency 1.4MHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 16-VFQFN Exposed Pad
Supplier Device Package 16-QFN (3x3)
Manufacturer Pack Quantity 1
MSL Level 2 (1 Year)
Win Source Part Number 757658-TPS62095RGTR
Family Name TPS62095
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS62095RGTR CAD Model

Description

The TPS62095RGTR is a high-efficiency synchronous step-down converter designed by Texas Instruments, known for its compact size and exceptional power management capabilities. This advanced power solution is optimized for portable and space-constrained applications where efficiency and reliability are critical.

Key Features

  • Input Voltage Range: The device supports a wide input voltage range from 2.5V to 6V, making it versatile for various applications.
  • High-Efficiency: With up to 95% efficiency, the TPS62095RGTR ensures minimal power loss and extends battery life in portable devices.
  • Adjustable Output Voltage: The output voltage is adjustable from 0.8V to Vin, allowing for use in a range of applications requiring different voltage levels.
  • Current Capability: The device can deliver up to 4A of continuous output current, suitable for high-power applications.
  • Power Save Mode: It includes a Power Save Mode for improved efficiency at light loads, which is beneficial for battery-powered devices.
  • Thermal and Overcurrent Protection: The converter features built-in thermal shutdown and overcurrent protection to safeguard the device and the load under extreme conditions.
  • Small Footprint: Housed in a 16-pin QFN package, the TPS62095RGTR offers a compact solution, ideal for space-constrained applications.

Applications

The TPS62095RGTR is suitable for a variety of applications, including but not limited to:

  • Smartphones and Tablets
  • Wireless Power Transmitters
  • Portable and Battery-Powered Equipment
  • Data Storage Systems
  • Networking and Telecom Infrastructure

Quality and Reliability

Texas Instruments is committed to delivering high-quality and reliable components. The TPS62095RGTR is no exception, as it is designed and tested to meet stringent industry standards, ensuring performance and longevity in demanding environments.

For detailed technical specifications, application notes, and support resources, please refer to the official Texas Instruments product page and datasheets.
