TPS3710DDCR

Part No TPS3710DDCR
Manufacturer Texas Instruments
Catalog PMIC - Supervisors
Description IC SUPERVISOR 1 CHANNEL TSOT23-6
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Supervisors
Mfr Texas Instruments
Package Tape & Reel
Product Status Active
Programmable Not Verified
Type Voltage Detector
Number of Voltages Monitored 1
Voltage - Threshold Adjustable/Selectable
Output Open Drain or Open Collector
Reset Active Low
Reset Timeout 0ms Typical
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case SOT-23-6 Thin, TSOT-23-6
Supplier Device Package SOT-23-THIN
Base Product Number TPS3710
Standard Package 3,000 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 848675-TPS3710DDCR
Ultra Librarian 3D Model Ultra Librarian TPS3710DDCR CAD Model

Description

Product Overview: Texas Instruments TPS3710DDCR

The Texas Instruments TPS3710DDCR is a high-precision, dual-window voltage detector designed for systems that require an advanced level of voltage monitoring. This device is particularly suited for applications that need to ensure proper operation within certain voltage thresholds, such as in industrial control systems, computing equipment, and portable electronics.

The TPS3710DDCR combines two comparators with a 400-mV reference in a small, 6-pin SOT-23 package. The integrated comparators monitor two independent voltage rails and provide an output signal if either voltage goes outside the user-configurable window thresholds. This functionality is critical for systems that cannot tolerate voltage deviations, as it allows for immediate corrective action to be taken before any damage occurs.

Key Features

  • Precision Monitoring: With a tight 0.5% threshold accuracy over the entire temperature range, the TPS3710DDCR ensures reliable voltage monitoring, which is essential for sensitive electronic components.
  • Wide Supply Voltage Range: The device supports a supply voltage range from 1.8V to 18V, making it versatile for various applications and compatible with many different types of systems.
  • Low Quiescent Current: The TPS3710DDCR is optimized for low-power operation, drawing a quiescent current of just 6.5 µA, which is ideal for battery-powered devices.
  • Independent Window Thresholds: Users can set the voltage thresholds independently, providing flexibility and precise control over the monitoring system.
  • Push-Pull RESET Output: The device features a push-pull RESET output, which provides a clear and immediate signal when a voltage rail falls outside the pre-defined window, ensuring rapid response to potential issues.

Applications

  • Industrial Control Systems
  • Computing Equipment
  • Portable Electronics
  • Power Management Systems
  • Automotive Electronics

The TPS3710DDCR is a robust solution for any design that requires meticulous voltage supervision. Its high accuracy, low power consumption, and flexible configuration options make it an excellent choice for designers looking to enhance the reliability and safety of their electronic systems.
