The TPS2042DR from Texas Instruments is a sophisticated power management integrated circuit designed for USB applications. This state-of-the-art device offers dual-channel, current-limited, power distribution switches optimized for self-powered and bus-powered Universal Serial Bus (USB) applications.

Key Features

• Dual USB Ports: The TPS2042DR is capable of controlling two USB ports, providing independent over-current protection for each port, ensuring safe operation and protection for connected devices.
• Current Limiting: Each channel is individually current-limited to protect the host device against overcurrent events, such as short circuits or excessive power draw from connected peripherals.
• Thermal Shutdown: The device includes an integrated thermal shutdown feature that protects the chip and the connected devices from damage due to overheating.
• Fast Overcurrent Response: With a quick response time to overcurrent conditions, the TPS2042DR minimizes the risk of damage to circuit components.
• Wide Voltage Range: This switch operates over a wide input voltage range from 2.7V to 5.5V, accommodating a variety of USB applications.
• Low Standby Current: It is designed with a low standby current, which is ideal for portable applications where power conservation is critical.

Applications

The TPS2042DR is suitable for a broad range of applications. It is particularly useful in:

• USB Hubs
• Desktop Computers
• Notebook Computers
• Docking Stations
• Monitors with USB Ports

Technical Specifications

The TPS2042DR's compact SOIC-8 package makes it an excellent choice for space-constrained USB applications. With its robust protection features and efficient power management, this switch ensures reliable and safe operation of USB peripheral devices.
