TPD1E01B04DPYR

Part No TPD1E01B04DPYR
Manufacturer Texas Instruments
Catalog TVS - Diodes
Description TVS DIODE 3.6VWM 15VC 2X1SON / 15V Clamp 2.5A Ipp Tvs Diode Surface Mount 2-X1SON (1x.60)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Texas Instruments
Package Tape & Reel
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 3.6V
Voltage - Breakdown (Min) 6.4V
Voltage - Clamping (Max) @ Ipp 15V
Current - Peak Pulse (10/1000µs) 2.5A
Power - Peak Pulse 27W
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 0.2pF @ 1MHz
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Package / Case 0402 (1006 Metric)
Supplier Device Package 2-X1SON (1x.60)
Base Product Number TPD1E01B04
Standard Package 10,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 852467-TPD1E01B04DPYR
Ultra Librarian 3D Model Ultra Librarian TPD1E01B04DPYR CAD Model

Description

TPD1E01B04DPYR by Texas Instruments

The TPD1E01B04DPYR is a state-of-the-art ESD protection device from Texas Instruments designed to safeguard high-speed interfaces with minimal impact on signal integrity. This compact and efficient solution is ideal for a wide range of applications, including USB interfaces, HDMI ports, antenna terminals, and other high-frequency data lines.

Key Features

  • Low Capacitance: With a typical capacitance of only 0.25 pF per channel, the TPD1E01B04DPYR ensures high signal fidelity for high-speed data lines.
  • Dual-Channel Protection: This device features two channels of ESD protection, making it versatile for protecting differential pairs or two single-ended lines.
  • IEC Compatibility: It is designed to comply with the IEC 61000-4-2 (ESD) standard, providing robust protection against electrostatic discharges.
  • Ultra-Low Leakage: The ultra-low leakage current of less than 100 nA helps to conserve power in sensitive applications.
  • Small Footprint: The TPD1E01B04DPYR comes in a tiny DFN package, which is ideal for space-constrained designs.

Applications

The device's exceptional performance characteristics make it suitable for protecting a variety of high-speed data interfaces without compromising data integrity. Typical applications include:

  • USB 2.0 and 3.0 ports
  • HDMI 1.3/1.4/2.0 interfaces
  • DisplayPort interfaces
  • V-by-One HS
  • Thunderbolt ports
  • LVDS interfaces
  • RF Antenna terminals

Advantages

The TPD1E01B04DPYR offers several advantages to designers looking to enhance the durability and longevity of their electronic products:

  • Protects against common ESD events, reducing the risk of damage to sensitive components.
  • Preserves signal integrity for high-speed data transmission thanks to its low capacitance.
  • Supports a wide range of high-speed interfaces, providing a versatile solution for multiple applications.
  • Its small size allows for integration into compact designs without sacrificing performance.

Overall, the TPD1E01B04DPYR from Texas Instruments is an excellent choice for designers seeking reliable ESD protection without compromising on signal quality or board space.
