Product Overview: TLVH431AQDBVRQ1 from Texas Instruments

The TLVH431AQDBVRQ1, manufactured by Texas Instruments, is a high-performance, low-voltage adjustable precision shunt regulator. This semiconductor device is designed to provide a reliable and stable reference voltage for various automotive and industrial applications. With its adjustable output voltage and low dynamic impedance, the TLVH431AQDBVRQ1 stands out as an ideal choice for precision voltage regulation tasks.

Key Features

• Adjustable Output Voltage: The device offers an adjustable output voltage range from 1.24 V to 18 V, allowing for flexibility in application design.
• Low Output Noise: It ensures minimal noise in the output signal, making it suitable for noise-sensitive applications.
• High Precision: The TLVH431AQDBVRQ1 boasts a 0.5% reference voltage tolerance at 25°C, providing high accuracy for critical applications.
• Low Dynamic Impedance: With a dynamic impedance of 0.22 Ω (typical), the device ensures stable operation under varying load conditions.
• Wide Operating Current Range: It operates over a wide current range from 1 mA to 100 mA, accommodating a broad spectrum of applications.
• Extended Temperature Range: The device is designed to operate over an automotive temperature range from -40°C to 125°C, making it highly reliable in extreme conditions.
• Robust Packaging: Packaged in a small-outline transistor SOT-23 (DBVR) package, the TLVH431AQDBVRQ1 is optimized for space-constrained applications.
• Quality and Reliability: As a Q1 automotive-grade product, it meets the stringent requirements for automotive applications, ensuring high levels of quality and reliability.

Applications

The TLVH431AQDBVRQ1 is well-suited for a range of applications, including:

• Automotive systems
• Power supplies
• Battery chargers
• Voltage monitoring
• Adjustable voltage references
• Instrumentation

With its precision performance and durable design, the TLVH431AQDBVRQ1 from Texas Instruments is an excellent choice for designers looking for a reliable voltage reference solution in their automotive or industrial electronic systems.
