The TL072ACDR is a high-performance JFET-input operational amplifier integrated circuit (IC) designed and manufactured by Texas Instruments (TI), a leader in semiconductor solutions. This IC is known for its low input bias and offset currents, as well as low noise and high speed, making it an excellent choice for a wide range of audio and signal processing applications.

Key Features

• Low Power Consumption: The TL072ACDR operates with a typical low quiescent current, which is ideal for battery-powered devices and energy-efficient designs.
• High Input Impedance: The JFET input stage offers high input impedance, ensuring minimal loading on the signal source.
• Low Input Bias and Offset Currents: These characteristics result in better accuracy and stability in signal amplification and processing tasks.
• Low Noise: The device provides a low noise floor, which is crucial for high-fidelity audio applications and sensitive instrumentation.
• Wide Common-Mode and Differential Voltage Ranges: This allows the IC to operate in a broad range of applications without the risk of phase reversal.
• High Slew Rate: The TL072ACDR offers a high slew rate, enabling it to handle rapid changes in input signals effectively.

Applications

• Audio Pre-Amplifiers and Mixers
• Active Filters
• Signal Processing
• Analog-to-Digital Converters (ADCs)

Package and Quality

The TL072ACDR comes in a compact 8-pin SOIC package, which is suitable for space-constrained applications. It is RoHS compliant and supports a commercial temperature range, ensuring reliability and performance across various environments.

Technical Specifications

The operational amplifier has a typical dual supply voltage of ±15V, but it can operate from a single supply of 5V to 30V or dual supplies of ±2.5V to ±15V. The TL072ACDR also features a bandwidth of 3MHz and a typical slew rate of 13V/μs, delivering swift and accurate signal amplification.

For detailed specifications, application notes, and support resources, engineers and designers can visit Texas Instruments' official website or contact their support team for further assistance.
