Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel
The number of I/O 8
Interface I2C
Interrupt Output Yes
Output Type Push-Pull
Clock Frequency 400kHz
Supply Voltage (V) 1.65V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 16-TSSOP
Supplier Device Package 16-TSSOP
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1265520-TCA9534PWR
Manufacturer Homepage www.ti.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TCA9534
Introduction Date September 23, 2014
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TCA9534PWR CAD Model

Description

The TCA9534PWR is a sophisticated Remote 8-Bit I/O Expander for I²C Bus designed by Texas Instruments, one of the leading manufacturers in the semiconductor industry. This integrated circuit is engineered to provide general-purpose remote I/O expansion for most microcontroller families via the two-wire bidirectional I²C bus (serial clock (SCL), serial data (SDA)).

Key Features

  • Low Standby Current: The device features a low standby current, which makes it suitable for power-sensitive applications.
  • Versatile Voltage Operation: It operates across a wide voltage range of 1.65 to 5.5 V, making it adaptable to various logic levels and supply voltages.
  • Enhanced Interface: The TCA9534PWR offers an interrupt output that can be connected to the interrupt logic of the microcontroller, thereby providing an efficient method of monitoring the input pins for changes without the need for constant polling.
  • Configurable Polarity: Input and output configuration settings are programmable, and the polarity of the I/O expander is also configurable, giving designers flexibility in hardware layout.

Applications

The versatility of the TCA9534PWR makes it an excellent choice for a broad range of applications, including:

  • Server Infrastructure
  • Factory Automation and Control
  • Electronics Signage
  • Industrial PCs

Package and Quality

The TCA9534PWR is offered in a TSSOP (Thin Shrink Small Outline Package) with 24 pins, which provides a compact footprint while allowing for adequate thermal performance. Texas Instruments is known for its commitment to quality, and this product is no exception. It is designed and manufactured to meet high standards, ensuring reliability and performance for critical applications.

Support and Resources

Designers can access comprehensive technical resources, including datasheets, application notes, and design tools, to facilitate the integration of the TCA9534PWR into their projects. Texas Instruments also provides customer support and an active community forum to assist with any design challenges.
