Product Description: Texas Instruments SN75176BD

The SN75176BD from Texas Instruments is a differential bus transceiver designed for bidirectional data communication on multipoint bus transmission lines. It is a highly reliable and efficient product that is used in a variety of applications, including telecommunications, industrial control, and data acquisition systems.

This device combines a 3-state differential line driver and a differential input line receiver, both of which operate from a single 5-V power supply. The driver and receiver have active-high and active-low enables, respectively, that can be connected together externally to function as a direction control. The SN75176BD driver's differential outputs and the receiver's differential inputs are connected internally to form a differential input/output (I/O) bus port that is designed to offer minimum loading to the bus when the transceiver is disabled.

Another impressive feature of the SN75176BD is its high-impedance output state during power up and power down, which allows power to be applied and removed in any order. This product meets or exceeds the requirements of ANSI TIA/EIA-422-B and ITU recommendation V.11. It is characterized for operation from 0°C to 70°C.

Key Features:

• Designed for multipoint transmission on long bus lines in noisy environments
• 3-state differential line driver and receiver in one package
• Operates from single 5-V supply
• Meets or exceeds ANSI TIA/EIA-422-B and ITU recommendation V.11
• High-impedance output state during power up and power down
• Characterized for operation from 0°C to 70°C

In conclusion, the SN75176BD from Texas Instruments is a reliable, efficient, and versatile differential bus transceiver that is well suited for a wide range of applications.
