SN74LVC1T45DBVT

Part No SN74LVC1T45DBVT
Manufacturer Texas Instruments
Catalog Logic - Translators, Level Shifters
Description SINGLE-BIT DUAL-SUPPLY BUS TRANSCEIVER WITH CONFIGURABLE VOLTAGE TRANSLATION AND 3-STATE OUTPUTS
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Series 74LVC
Packaging Reel - TR
Translator Type Voltage Level
Channel Type Bidirectional
Number of Circuits 1
Channels per Circuit 1
Voltage - VCCA 1.65V ~ 5.5V
Voltage - VCCB 1.65V ~ 5.5V
Output Type Tri-State, Non-Inverted
Data Rate 420Mbps
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting SMD
Package SOT-23-6
Manufacturer Package SOT-23-6
Win Source Part Number 1255589-SN74LVC1T45DBVT
Manufacturer Homepage www.ti.com
Family Name SN74LVC1T45
Introduction Date October 01, 2005
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Consumer Electronics, Industrial, Commercial, Communications & Networking
Ultra Librarian 3D Model Ultra Librarian SN74LVC1T45DBVT CAD Model

Description

SN74LVC1T45DBVT Single-Bit Dual-Supply Bus Transceiver with Configurable Voltage Translation and 3-State Outputs

The SN74LVC1T45DBVT from Texas Instruments is a versatile single-bit dual-supply bus transceiver designed for bidirectional voltage-level translation. It is ideal for applications that require the transfer of signals between different voltage domains. The device is part of the LVC family, which is known for its low-voltage operation and compatibility with mixed-voltage systems.

Key Features:

  • Voltage-Level Translation: The SN74LVC1T45DBVT is capable of translating signals between two different voltage nodes, allowing for seamless communication between devices operating at different voltage levels.
  • Dual-Supply Operation: It operates from 1.65 V to 5.5 V on the A side and 2.3 V to 5.5 V on the B side, which enables interfacing between a wide range of voltages.
  • Direction Control: The direction of data flow is determined by the DIR input, which allows for easy control of the transceiver's operation.
  • Output Enable (OE) Feature: The OE input can be used to place the output in a high-impedance state, thus allowing multiple devices to share a common data bus.
  • Low Power Consumption: It boasts a low power consumption, making it suitable for battery-operated and power-sensitive applications.
  • High-Speed Operation: The device supports high-speed signal transfer with minimal propagation delay, ensuring efficient communication between integrated circuits.

Applications:

The SN74LVC1T45DBVT is commonly used in a variety of applications that require voltage translation or mixed-voltage system integration, including:

  • Mobile Phones
  • Portable Electronics
  • Computing Devices
  • Consumer Electronics
  • Embedded Systems

Package and Quality:

This transceiver comes in a compact SOT-23-6 package, which is suitable for space-constrained applications. It is characterized for operation from -40°C to 85°C, ensuring reliability across a wide temperature range. Texas Instruments is committed to providing high-quality and reliable components, and the SN74LVC1T45DBVT is no exception, meeting strict industry standards for performance and durability.

For further information, including detailed specifications, data sheets, and support tools, visit the Texas Instruments official website or contact their customer support team.
