The SN74LVC1G332DCKR is a high-quality, single 2-input positive-OR gate device from Texas Instruments. This product is designed and manufactured by Texas Instruments, a renowned global semiconductor company that designs, manufactures, tests, and sells analog and embedded processing chips.

Product Specifications

The SN74LVC1G332DCKR operates from a wide voltage range of 1.65 V to 5.5 V, making it suitable for a range of applications. It offers excellent noise immunity performance thanks to its balanced output drive. The device is designed for 5.5-V VCC operation, and the inputs can tolerate voltages up to 5.5 V, allowing the device to be used in mixed-voltage systems.

Key Features

• Operates From 1.65 V to 5.5 V
• Inputs Accept Voltages to 5.5 V
• Max tpd of 5.5 ns at 3.3 V
• Low Power Consumption, 10-µA Max ICC
• Ioff Supports Live Insertion, Partial-Power-Down Mode, and Back-Drive Protection

Applications

The SN74LVC1G332DCKR is suitable for a wide range of applications. These include but are not limited to, servers, personal computers, routers, point-of-sale systems, test equipment, and industrial control.

Quality and Reliability

As with all Texas Instruments products, the SN74LVC1G332DCKR is built to deliver high performance and reliability. This product is RoHS compliant and is available in the small SC70-5 (DCK) package.

Ordering Information

For ordering the Texas Instruments SN74LVC1G332DCKR or for more information about this product, please visit the official Texas Instruments website or contact their customer service.
