The SN74LVC1G04DCKRG4 is a single inverter gate integrated circuit produced by Texas Instruments, renowned for its high-quality semiconductor devices. This particular component is a member of the 74LVC family, which is known for its low-voltage operation and compatibility with TTL (Transistor-Transistor Logic) levels, making it a versatile choice for a wide range of electronic applications.

Key Features

• Logic Type: The SN74LVC1G04DCKRG4 is designed as a single inverter logic gate, which inverts the input signal, providing an output that is the logical complement of the input.
• Supply Voltage: It operates at a supply voltage range of 1.65V to 5.5V, allowing for use in low-voltage applications while still maintaining compatibility with 5V systems.
• High-Speed: The device boasts a significant speed performance with a propagation delay time of typically 2.9 ns at 3.3V, ensuring swift signal processing in critical applications.
• Output Drive Capability: It can drive loads up to 24 mA, providing sufficient current for a variety of digital loads.
• Power Dissipation: With low power consumption, the SN74LVC1G04DCKRG4 offers a power dissipation capacitance of 10 pF at 3.3V, making it an energy-efficient option for power-sensitive designs.

Package and Quality

The device is available in a 5-pin SC70 package, which is compact and suitable for space-constrained applications. The small footprint allows designers to optimize board space without sacrificing performance.

Applications

The SN74LVC1G04DCKRG4 is ideal for use in a variety of electronic systems including:

• Servers
• Personal computers
• Networking equipment
• Portable electronics
• Signal conditioning
• Logic level translation

Environmental and Regulatory Compliance

Committed to environmental stewardship, Texas Instruments ensures that the SN74LVC1G04DCKRG4 complies with RoHS (Restriction of Hazardous Substances) standards, minimizing the presence of hazardous materials in electronic products.
