SN74AHC1G14DCKR

Name: SN74AHC1G14DCKR
Brand: Texas Instruments
SKU: 331590
Availability: InStock
Rating: 4.85 (166 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SN74AHC1G14DCKR
Manufacturer	Texas Instruments
Catalog	Logic - Gates and Inverters
Description	IC SGL SCHMT-TRG INV GATE SC70-5 / Inverter Schmitt Trigger 1-Element CMOS 5-Pin SC-70 T/R
Datasheet	SN74AHC1G14DCKR Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	1
Number of Inputs	1
Features	Schmitt Trigger
Supply Voltage - Operating	2 V to 5.5 V
Current - Quiescent (Max)	1μA
Current - Output High, Low	8mA, 8mA
Logic Level - Low	0.9 V to 1.65 V
Logic Level - High	2.2 V to 3.85 V
Max Propagation Delay @ V, Max CL	10.6ns @ 5V, 50pF
Temperature Range - Operating	-40°C to 125°C
Mounting	SMD (SMT)
Case / Package	SC-70-5
Dimension	5-TSSOP, SC-70-5, SOT-353
Win Source Part Number	095602-SN74AHC1G14DCKR
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Industrial
Family Name	SN74AHC1G14
Introduction Date	November 01, 2009
ECCN	EAR99
Country of Origin	China, Malaysia, Thailand
Halogen Free	Compliant
Estimated EOL Date	2031
Ultra Librarian 3D Model	Ultra Librarian SN74AHC1G14DCKR CAD Model

Alternative Products

Description

The SN74AHC1G14DCKR is a high-performance, advanced integrated circuit product from Texas Instruments, a renowned leader in semiconductor solutions.

Type: Single gate Schmitt-trigger inverter
Technology: Advanced CMOS
Boolean function: Y = A
Operating Temperature: -40°C to 85°C
Package: 5-pin SC-70
Supply Voltage Range: 2V to 5.5V
Noise Immunity: High
Feature: Schmitt-trigger action at all inputs
