The SN74HC4060QDRQ1 is a high-quality integrated circuit from Texas Instruments, designed specifically for automotive and industrial applications. This robust device is a 14-stage binary counter with an on-board oscillator, making it ideal for timing and counting operations in a wide range of electronic systems.

Key Features:

• Binary Counter: The device features a 14-stage ripple-carry binary counter, which can be used in frequency division or as a time delay element in various applications.
• Oscillator Functionality: An integrated oscillator is provided, which requires only an external resistor and a capacitor to set the desired oscillation frequency.
• Wide Operating Voltage: It operates over a broad voltage range of 2 V to 6 V, offering flexibility for use in different system voltages.
• High-Current Outputs: The outputs can drive up to 10 LSTTL loads, ensuring compatibility with various logic families and the ability to drive multiple devices.
• Automotive Qualified: As a Q1 device, it meets the rigorous standards of the automotive industry, ensuring reliability and performance under harsh conditions.

Applications:

The versatile nature of the SN74HC4060QDRQ1 makes it suitable for a variety of applications, including:

• Automotive systems
• Timing circuits
• Frequency counters
• Time-delay circuits
• Industrial control systems

Package and Quality:

The device comes in a small-outline package, making it suitable for space-constrained applications. The SN74HC4060QDRQ1 is also part of Texas Instruments' commitment to quality, with rigorous testing to ensure it meets the high standards required for use in automotive applications.

Ordering Information:

For detailed product specifications, ordering information, and support, please visit the Texas Instruments website or contact an authorized distributor. The SN74HC4060QDRQ1 is available for order in various quantities to meet the needs of your project or product design.
