The SN74AUP3G14DQER by Texas Instruments is a high-performance, triple Schmitt-trigger inverter optimized for low-power and low-voltage applications. This integrated circuit is designed for exceptional power efficiency while maintaining excellent switching characteristics, making it an ideal choice for battery-operated and power-sensitive devices.

Key Features

• Low Power Consumption: The device features ultra-low static power consumption of only 0.9 µA maximum at 3.6 V, which helps to extend battery life in portable applications.
• Low Voltage Operation: It operates at a voltage range of 0.8 V to 3.6 V, enabling its use in systems that require low-voltage logic levels.
• High Drive Capability: Despite its low-power design, the SN74AUP3G14DQER can drive up to ±8 mA at 3.3 V, allowing it to control a variety of peripheral components.
• Schmitt-Trigger Inputs: The Schmitt-trigger inputs provide hysteresis, which enhances noise immunity and allows for slow input transition rates, making the device suitable for noisy environments.
• Multiple Configurations: The triple inverter configuration offers design flexibility, enabling the use of one integrated circuit for multiple purposes within a circuit design.

Applications

With its versatile features, the SN74AUP3G14DQER is well-suited for a wide range of applications, including:

• Smartphones and Tablets
• Portable Medical Devices
• Wearable Technology
• Energy Management Systems
• IoT Devices

Package and Quality

The device is available in a space-saving DQFN-14 (R-PDSO-G14) package, which is lead-free and RoHS compliant. Texas Instruments is committed to high-quality manufacturing standards, ensuring that the SN74AUP3G14DQER meets the stringent requirements of the electronics industry for reliability and performance.
