SN74AHC14PW

Name: SN74AHC14PW
Brand: Texas Instruments
SKU: 331536
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	SN74AHC14PW
Manufacturer	Texas Instruments
Catalog	Logic - Gates and Inverters
Description	IC HEX SCHMITT-TRIG INV 14TSSOP
Datasheet	SN74AHC14PW Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	6
Number of Inputs	6
Features	Schmitt Trigger
Supply Voltage - Operating	2 V to 5.5 V
Current - Quiescent (Max)	2μA
Current - Output High, Low	8mA, 8mA
Logic Level - Low	0.9 V to 1.65 V
Logic Level - High	2.2 V to 3.85 V
Max Propagation Delay @ V, Max CL	10.6ns @ 5V, 50pF
Temperature Range - Operating	-40°C to 125°C
Mounting	SMD (SMT)
Case / Package	14-TSSOP
Dimension	14-TSSOP (0.173", 4.40mm Width)
Win Source Part Number	082203-SN74AHC14PW
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian SN74AHC14PW CAD Model

Alternative Products

Description

The SN74AHC14PW is a high-performance integrated circuit (IC) developed by Texas Instruments, a renowned global semiconductor design and manufacturing company.

Series: SN74AHC
Function: Hex Schmitt-Trigger Inverter
Operating Voltage Range: 2 to 5.5 Volts
Noise Immunity: High
Power Consumption: Low
Current Drive: ±8mA @ 5V
Package: TSSOP (Thin Shrink Small Outline Package) with 14 pins
RoHS Compliant: Yes
