Product Overview: SN74ABT3612-15PCB

The SN74ABT3612-15PCB is a high-performance integrated circuit from Texas Instruments, renowned for its reliability and versatility in various digital applications. This device is part of the ABT family, which is known for advanced BiCMOS technology, offering both the speed of CMOS and the low power dissipation of TTL.

Key Features

• High-Speed Operation: The SN74ABT3612-15PCB is designed for clocked latch operations, allowing for rapid data storage and retrieval, making it suitable for high-speed systems where timing is critical.
• Low Power Consumption: Despite its high-speed capabilities, this integrated circuit maintains low power consumption, which is ideal for power-sensitive designs.
• Bus-Hold Data Inputs: The device comes with bus-hold data inputs that eliminate the need for external pull-up or pull-down resistors, simplifying board design and reducing overall system cost.
• 3-State Outputs: It features 3-state outputs that increase its flexibility in bus-oriented applications by allowing the outputs to be put into a high-impedance state, effectively disconnecting them from the bus.

Product Specifications

• Logic Type: Clocked Latch
• Number of Bits per Element: 18
• Output Type: 3-State
• Operating Temperature: -40°C to +85°C
• Package / Case: 56-SSOP (0.209", 5.30mm Width)
• Mounting Type: Surface Mount
• Supply Voltage: 4.5V to 5.5V

Applications

The SN74ABT3612-15PCB is suitable for a wide range of applications where data integrity and speed are paramount. It is commonly used in:

• Data storage systems
• Communications infrastructure
• Computers and computer peripherals
• Networking equipment

With its robust design and advanced features, the SN74ABT3612-15PCB from Texas Instruments is an excellent choice for designers looking to integrate a reliable clocked latch into their digital systems.
