REF3020AIDBZR Real Image REF3020AIDBZR real image5064 REF3020AIDBZR Real Image1 REF3020AIDBZR Real Image2 REF3020AIDBZR Real Image3 REF3020AIDBZR Real Image4 REF3020AIDBZR Real Image5 REF3020AIDBZR Real Image6 REF3020AIDBZR Real Image7 REF3020AIDBZR Real Image8 REF3020AIDBZR Real Image9
Same model may have multiple batches, images only for reference.
REF3020AIDBZR Real Image REF3020AIDBZR real image5064 REF3020AIDBZR Real Image1 REF3020AIDBZR Real Image2 REF3020AIDBZR Real Image3 REF3020AIDBZR Real Image4 REF3020AIDBZR Real Image5 REF3020AIDBZR Real Image6 REF3020AIDBZR Real Image7 REF3020AIDBZR Real Image8 REF3020AIDBZR Real Image9
REF3020AIDBZR Real Image REF3020AIDBZR real image5064 REF3020AIDBZR Real Image1 REF3020AIDBZR Real Image2 REF3020AIDBZR Real Image3 REF3020AIDBZR Real Image4 REF3020AIDBZR Real Image5 REF3020AIDBZR Real Image6 REF3020AIDBZR Real Image7 REF3020AIDBZR Real Image8 REF3020AIDBZR Real Image9
Same model may have multiple batches, images only for reference.

REF3020AIDBZR

Part No REF3020AIDBZR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Reference
Description IC VREF SERIES 2.048V SOT23-3
Datasheet
REF3020AIDBZR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Reference Type Series
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 2.048V
Output Current 25mA
Tolerance ±0.2%
Temperature Coefficient 75ppm/°C
Noise - 0.1Hz to 10Hz 23μVp-p
Noise - 10Hz to 10kHz 65μVrms
Voltage - Input 2.098 V to 5.5 V
Operating Supply Current 50μA
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 027302-REF3020AIDBZR
Family Name REF3020
Introduction Date June 20, 2005
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Signal Processing, Portable Devices, Test & Measurement, Medical, Power Management
Ultra Librarian 3D Model Ultra Librarian REF3020AIDBZR CAD Model

Description

The REF3020AIDBZR from Texas Instruments is a high-performance, low-power, precision voltage reference product.

  • Output Voltage: Fixed 2.048V output voltage.
  • Temperature Drift: 50ppm/°C (max) over -40°C to +125°C.
  • Quiescent Current: 100µA (max).
  • Dropout Voltage: 180mV.
  • Output Current: 10mA.
  • Initial Accuracy: 0.2% (max).
  • Package: Small DBZ (SOT-23-3) package.
  • Compliance: RoHS compliant.
