PCA9546APW Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer Texas Instruments
Standard Package 90
Category Integrated Circuits(ICs)
Family Interface - Specialized
Packaging Tube
Applications Translating Switch
Interface I²C SMBus
Operating Supply Voltage 2.3 V ~ 5.5 V
Package 16-TSSOP (0.173" 4.40mm Width)
Manufacturer Device Package 16-TSSOP
Mounting Style SMD/SMT
Catalog Texas Instruments
Win Source Part Number 090187-PCA9546APW
Family Name PCA9546
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Automotive, Building Automation, Motor Drive & Control
Ultra Librarian 3D Model Ultra Librarian PCA9546APW CAD Model

Description

The PCA9546APW is a sophisticated and high-performing product developed by Texas Instruments, a renowned name in the semiconductor industry.

  • Description: 4-channel I2C bus switch with reset
  • Channels: Operates in four separate I2C buses or channels, software-selected through the control register
  • Features: Power-on reset function, active LOW reset input
  • Standards: Supports standard-mode and fast-mode I2C devices, compatible with SMBus standards
  • Voltage: Supply voltage range of 2.3V to 5.5V
  • Interrupt Output: Configurable to alert the system in case of any issues
  • Package: TSSOP (Thin Shrink Small Outline Package) with 20 pins
  • I/Os: Over-voltage tolerant I/Os
  • Applications: Server environments, telecom systems, and industrial applications
