PCA9534ADB Real Image PCA9534ADB Real Image
Same model may have multiple batches, images only for reference.
PCA9534ADB Real Image PCA9534ADB Real Image
PCA9534ADB Real Image PCA9534ADB Real Image
Same model may have multiple batches, images only for reference.

PCA9534ADB

Part No PCA9534ADB
Manufacturer Texas Instruments
Catalog HOT - SALES and EOL Components
Description IC I/O EXPANDER I2C 8B 16SSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube
The number of I/O 8
Interface I2C, SMBus
Interrupt Output Yes
Features POR
Output Type Push-Pull
Current - Output Source/Sink 10mA, 25mA
Clock Frequency 400kHz
Supply Voltage (V) 2.3V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 16-SSOP
Supplier Device Package 16-SSOP
Family Part Number PCA9534A
Manufacturer Pack Quantity 80
MSL Level 1 (Unlimited)
Win Source Part Number 269654-PCA9534ADB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PCA9534ADB CAD Model

Description

The PCA9534ADB is a high-quality, advanced, low-voltage 8-bit I/O expander produced by Texas Instruments, a globally recognized leader in semiconductor technology.

  • Product: PCA9534ADB
  • Manufacturer: Texas Instruments
  • Description: 8-bit I/O expander for most microcontroller families via the I2C and SMBus interfaces
  • Components: 8-bit configuration register, 8-bit input port register, 8-bit output port register, and an 8-bit polarity inversion register
  • Feature: Interrupt output
  • Feature: Active LOW reset input
  • Power supply range: 2.3V to 5.5V
  • Feature: Built-in power-on reset
  • Feature: Supports both hardware and software address programming
  • Package: Small 20-pin TSSOP package
  • Operating temperature range: -40°C to +85°C
