The OPA4322AIPWR is a precision operational amplifier from Texas Instruments, designed to meet the needs of a wide range of electronic applications. This high-performance op-amp is part of the OPAx322 family and is particularly suitable for applications requiring low noise, high speed, and precision.

Key Features

• High Speed: The OPA4322AIPWR offers a fast settling time, making it ideal for high-speed data acquisition systems and digital-to-analog conversion processes.
• Low Noise: With its low-noise characteristics, this operational amplifier ensures signal integrity, which is critical in sensitive audio and instrumentation applications.
• Precision: The device provides excellent dc precision with low offset voltage and drift, ensuring accurate measurements and stable performance over time and temperature variations.
• Wide Supply Range: It operates over a wide supply range, accommodating various applications from battery-powered devices to industrial equipment.
• Power Efficiency: This op-amp is designed for power-sensitive applications, offering a balance between performance and power consumption.

Applications

The OPA4322AIPWR is versatile and can be used in multiple applications, including:

• Test and measurement equipment
• Audio processing
• Data acquisition systems
• Active filters
• Precision analog circuits

Product Specifications

• Package/Case: TSSOP-14
• Mounting Type: Surface Mount
• Number of Channels: 4
• Bandwidth: 10 MHz
• Slew Rate: 10 V/µs
• Supply Voltage: ±2.25V to ±18V, or 4.5V to 36V on a single supply
• Operating Temperature Range: -40°C to +125°C

Additional Information

The OPA4322AIPWR operational amplifier is delivered in a thin shrink small-outline package (TSSOP), which is optimized for improved thermal performance and reduced footprint on PCBs. Texas Instruments provides comprehensive support for their products, including detailed datasheets, application notes, and design resources to facilitate the integration of the OPA4322AIPWR into various applications.
