Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Receiver
Protocol RS422, RS423
Number of Drivers/Receivers 0/4
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 022698-MC3486DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name MC3486
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian MC3486DR CAD Model

Description

The MC3486DR is a high-quality, high-performance product from the globally recognized brand, Texas Instruments.

  • Product Type: Differential bus transceiver
  • Application: Bidirectional data communication on multipoint bus transmission lines
  • Family: SN65HVD10x family
  • Designed for: Balanced transmission lines
  • Supply Voltages: 4.5V to 5.5V
  • Key Feature: High input impedance
  • Data Rate: Up to 10 Mbps
  • Durability: Designed for harsh environmental conditions
  • Operating Temperature Range: -40°C to 85°C
  • Package: Compact, surface-mount package
  • Power Consumption: Low
