Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage (V) 3V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 16-SOIC
Supplier Device Package 16-SOIC
Family Part Number MAX3232
Manufacturer Pack Quantity 40
MSL Level 1 (Unlimited)
Win Source Part Number 210655-MAX3232ID
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Portable Devices, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian MAX3232ID CAD Model

Description

The MAX3232ID from Texas Instruments is an advanced integrated circuit device designed to facilitate the conversion of signals between RS-232 and TTL/CMOS levels.

  • Device Type: Dual Driver/Receiver
  • Power Supply: Single 5V
  • Low-Power Shutdown Mode: Yes
  • Data Signaling Rate: Up to 250 kbps
  • ESD Protection (HBM): Exceeds ±15 kV
  • Flexible Voltage Range: Works with both 3.3V and 5V logic
  • Receivers: 2
  • Drivers: 2
  • Package: 16-pin SOIC
  • Compliance: RoHS compliant, free from lead, halogen, and antimony
