Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-TSSOP
Win Source Part Number 021520-MAX3232EIPWR
Family Name MAX3232E
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MAX3232E
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian MAX3232EIPWR CAD Model

Description

The MAX3232EIPWR is a robust product from Texas Instruments, a renowned global semiconductor company that designs, manufactures, tests and sells analog and embedded processing chips.

  • Category: Interface ICs, Transceivers
  • Function: Dual Driver/Receiver
  • Voltage Generator: Capacitive, supplies TIA/EIA-232-F voltage levels from a single 3.3-V supply
  • Data Signaling Rate: Up to 250kbps
  • Power Supply: Single 3.0-V to 5.5-V
  • Drivers Protection: Short-circuit current limited, thermal shutdown
  • Receivers Feature: Minimum input hysteresis of 300 mV
  • Package: TSSOP
  • Operating Temperature: -40°C to 85°C
  • Compliance: RoHS compliant and lead-free
