Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 207376-MAX3232CDRG4
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Computers & Computer Peripherals, Portable Devices
Ultra Librarian 3D Model Ultra Librarian MAX3232CDRG4 CAD Model

Description

The MAX3232CDRG4 is a high-quality, innovative product from Texas Instruments, a renowned multinational semiconductor company that designs and manufactures advanced integrated circuits.

  • Product Type: Line driver/receiver
  • VCC Supply Voltage: 3.0V to 5.5V
  • Drivers/Receivers: 2-driver, 2-receiver
  • Communication Interfaces: RS-232 and V.28
  • ESD Protection: ±15kV
  • Feature: Automatic power-down
  • Data Rate: Up to 250 kbps
  • Standby Mode: Low-power standby mode
  • Temperature Range: -40°C to 85°C
  • Package: 16-pin thin shrink small-outline package (TSSOP)
