LM6172IM Real Image LM6172IM Real Image1 LM6172IM Real Image2 LM6172IM Real Image3 LM6172IM Real Image4
Same model may have multiple batches, images only for reference.
LM6172IM Real Image LM6172IM Real Image1 LM6172IM Real Image2 LM6172IM Real Image3 LM6172IM Real Image4
LM6172IM Real Image LM6172IM Real Image1 LM6172IM Real Image2 LM6172IM Real Image3 LM6172IM Real Image4
Same model may have multiple batches, images only for reference.

LM6172IM

Part No LM6172IM
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP VFB 100MHZ 8SOIC
Datasheet
LM6172IM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type Voltage Feedback
Number of Circuits 2
Slew Rate 3000 V/μs
Gain Bandwidth Product (GBP) 100MHz
-3db Bandwidth 160MHz
Current - Input Bias 1.2μA
Voltage - Input Offset 400μV
Operating Supply Current 4.6mA
Channel Output Current 90mA
Supply Voltage - Operating 5.5 V to 36 V, ±2.75 V to 18 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 082840-LM6172IM
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Sensing & Instrumentation, Communications & Networking, Multimedia, Imaging, Video & Vision, Signal Processing
Ultra Librarian 3D Model Ultra Librarian LM6172IM CAD Model

Description

The is a high-speed, low-power, dual operational amplifier from Texas Instruments. It is designed to provide a perfect blend of performance, reliability, and versatility.

  • High Slew Rate: 3600 V/µs
  • Gain Bandwidth Product: 100 MHz
  • Low Total Harmonic Distortion (THD): -66 dBc
  • Low Power Consumption: 2.6 mA per channel
  • High Output Drive Capability: 75 mA
  • Wide Supply Voltage Range: ±5V to ±15V
  • Features: Short-circuit protection, thermal shutdown protection
  • Package: 8-pin SOIC
  • Applications: High-speed communication systems, battery-powered devices, and high-precision instruments
