LM5106SD/NOPB

Part No LM5106SD/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Gate Drivers
Description IC GATE DVR HALF BRIDGE 10WSON
Datasheet
LM5106SD/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Synchronous
Number of Drivers 2
Gate Type N-Channel MOSFET
Supply Voltage - Operating 8 V to 14 V
Logic Voltage - VIL, VIH 0.8V, 2.2V
Current - Peak Output (Source, Sink) 1.2A, 1.8A
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 118V
Rise and Fall Time 15ns, 10ns
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 10-WSON (4x4)
Win Source Part Number 019390-LM5106SD/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM5106SD/NOPB CAD Model

Description

The LM5106SD/NOPB is a high-performance, feature-rich gate driver designed and manufactured by Texas Instruments, a leading global semiconductor company renowned for its comprehensive portfolio of advanced integrated circuits (ICs).

  • Operating Voltage Range: 5.5V to 100V
  • Peak Output Current: 2.5A
  • Package: 10-pin WSON
  • Operating Temperature Range: -40°C to 125°C
