LM3420M5X-4.2 Real Image LM3420M5X-4.2 real image1397
Same model may have multiple batches, images only for reference.
LM3420M5X-4.2 Real Image LM3420M5X-4.2 real image1397
LM3420M5X-4.2 Real Image LM3420M5X-4.2 real image1397
Same model may have multiple batches, images only for reference.

LM3420M5X-4.2

Part No LM3420M5X-4.2
Manufacturer Texas Instruments
Catalog PMIC - Battery Chargers
Description IC CTRLR LI-ION BAT CHRG SOT23-5
Datasheet
LM3420M5X-4.2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Battery Chemistry Lithium-Ion
Number of Cells 1
Battery Pack Voltage 4.2V
Maximum Supply Voltage 20V
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package SOT-23-5
Win Source Part Number 071247-LM3420M5X-4.2
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM3420M5X-4.2 CAD Model

Description

The LM3420M5X-4.2 is a sophisticated lithium-ion battery charger controller manufactured by Texas Instruments, a global leading semiconductor company.

  • Features: a constant voltage and constant current (CVCC) charge management function.
  • Input voltage range: 4.5V to 24V
  • Designed with precision: 0.5% reference voltage accuracy
  • Feature: under-voltage lockout feature
  • Versatile product that can be used in: a variety of applications.
  • Package: 5-pin SOT-23 package
  • Designed to work with: minimal external components
