Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Differential
Number of Elements 2
Output Type CMOS, MOS, Open-Collector, TTL
Supply Voltage - Operating 2 V to 36 V, ±1 V to 18 V
Voltage - Input Offset (Max) 5mV @ 30V
Current - Input Bias (Max) 0.25μA @ 5V
Current - Output (Typ) 20mA
Current - Quiescent (Max) 2.5mA
Temperature Range - Operating -25°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 082669-LM293D
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Sensing & Instrumentation, Computers & Computer Peripherals, Motor Drive & Control, Test & Measurement
Ultra Librarian 3D Model Ultra Librarian LM293D CAD Model

Description

The LM293D is a differential from Texas Instruments that is designed for power management applications.

  • Voltage Input Offset: 5mV @ 30V
  • Current Input Bias: 0.25μA @ 5V
  • Current Output: 20mA
  • Package: 8-SOIC
  • Temperature Range: -25°C to 85°C
  • Supply Voltage: 2 V to 36 V, ±1 V to 18 V
  • Commonly Used In: sensing & instrumentation, computers & computer peripherals, motor drive & control, and test & measurement
