The LM2904ITPX/NOPB is a versatile dual operational amplifier (op-amp) developed by Texas Instruments, designed for applications requiring a wide range of input voltages. This integrated circuit is part of the LM2904 series and is characterized by its robust performance, low power consumption, and high stability. It is well-suited for a variety of electronic applications, including sensor interfaces, power supplies, and audio amplifiers.

Key Features

• Wide Supply Voltage Range: The LM2904ITPX/NOPB operates on a supply voltage range from 3V to 32V for single supply configurations, or ±1.5V to ±16V for split supply configurations, making it adaptable to both low and high voltage applications.
• Low Input Bias Current: This op-amp features a low input bias current, which is ideal for applications that require high input impedance and minimal error due to bias current.
• High Gain Bandwidth Product: With a typical gain bandwidth product of 1 MHz, the LM2904ITPX/NOPB is capable of amplifying signals with a wide range of frequencies.
• Extended Industrial Temperature Range: It is designed to operate reliably in an extended industrial temperature range from -40°C to +125°C, ensuring consistent performance in harsh environments.
• Robust Output Drive Capability: The op-amp can drive capacitive loads and is capable of delivering output currents without significant distortion.
• Low Quiescent Current: It maintains low quiescent current, which is beneficial for battery-powered devices, reducing power consumption and extending battery life.

Applications

The LM2904ITPX/NOPB is designed to be a flexible component suitable for a wide range of applications. It is commonly used in sensor amplifiers, active filters, general purpose amplifiers, DC gain blocks, and many other circuits where a reliable dual operational amplifier is needed.

Package and Quality

This op-amp is offered in a compact, surface-mount 8-pin X2SON package, which is ideal for space-constrained applications. The "NOPB" suffix indicates that the product is lead-free and RoHS compliant, making it an environmentally friendly choice for modern electronic designs. Texas Instruments ensures high-quality standards, and the LM2904ITPX/NOPB is no exception, providing reliable and consistent performance for a wide array of electronic applications.
