The LM285BXZ-2.5/NOPB is a precision micro-power shunt voltage reference from Texas Instruments, providing a stable 2.5V output voltage with an accuracy of ±1%. This voltage reference IC is a versatile component designed for a wide array of applications, including power supplies, battery-operated equipment, and precision data conversion systems.

Key Features

• Output Voltage: Precisely regulated 2.5V with low-output voltage temperature coefficient, ensuring minimal voltage variation over temperature changes.
• Low Dynamic Impedance: The dynamic impedance of the device is less than 1Ω, which helps to maintain output voltage stability under varying load conditions.
• Wide Operating Current: Operates over a current range of 20µA to 20mA, offering flexibility for different design requirements.
• Extended Temperature Range: Suitable for use across a wide temperature range from -40°C to +85°C, making it ideal for challenging environments.
• Package: Available in a TO-92 package, which is known for its ease of handling and integration into a variety of circuit designs.
• Lead-Free and RoHS Compliant: The NOPB designation indicates that this product is lead-free and RoHS compliant, making it suitable for use in environmentally sensitive applications.

Applications

The LM285BXZ-2.5/NOPB is suitable for a multitude of applications. It is commonly used in portable battery-powered devices due to its low power consumption. Its precision voltage reference is ideal for analog-to-digital converters (ADCs) and digital-to-analog converters (DACs), ensuring accurate data conversion. Additionally, it can be used in power supply control and monitoring, where stable reference voltage is critical for proper operation.

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the LM285BXZ-2.5/NOPB is no exception. This product is designed and manufactured to meet the highest standards, ensuring consistent performance and longevity in your application.

For detailed specifications, application notes, and additional resources, please refer to the official Texas Instruments datasheet for the LM285BXZ-2.5/NOPB.
