ISO7242CDW Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 2/2
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Pulse Width Distortion (Max) 2.5ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 082552-ISO7242CDW
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial, Computers & Computer Peripherals, Automation & Process Control, Communications & Networking
Ultra Librarian 3D Model Ultra Librarian ISO7242CDW CAD Model

Description

The ISO7242CDW from Texas Instruments is a high-performance, quad-channel digital isolator designed to provide superior isolation and noise immunity for a wide range of applications.

  • Channels: Four isolated channels, with two forward and two reverse-direction channels.
  • Data Rates: Up to 25 Mbps
  • Isolation Performance: 2500 Vrms
  • Propagation Delay: Less than 50 ns
  • Package: Compact 16-pin SOIC package
  • Operating Temperature Range: -40°C to +125°C
  • Failsafe Output: Yes
  • Power Consumption: 1.9 mA per channel @ 1 Mbps
