The INA2180A4IDSGR is a state-of-the-art, dual-channel, current-sense amplifier designed and manufactured by Texas Instruments. This precision amplifier is tailored for power management applications that require accurate current monitoring and operational efficiency. Its high-quality construction and advanced features make it an ideal choice for a wide range of applications, including motor control, battery management, overcurrent protection, and power monitoring in industrial and automotive systems.

Key Features

• Integrated Dual Channels: This device features two independent current-sense amplifiers in one package, providing a compact solution for systems that need to monitor multiple currents simultaneously.
• High Accuracy: The INA2180A4IDSGR offers a high accuracy with a low offset voltage, ensuring precise current measurement for critical applications.
• Wide Common-Mode Range: The common-mode voltage range is broad, allowing the device to accurately measure current across shunt resistors in a variety of voltage environments.
• Low Power Consumption: Designed for efficiency, the amplifier operates with a low quiescent current, making it suitable for battery-powered and energy-sensitive applications.
• Adjustable Gain: The gain of the amplifier can be configured by external resistors, providing flexibility to adapt to different shunt resistor values and measurement ranges.

Applications

• Automotive systems
• Power management
• Battery chargers
• Motor control
• Overcurrent protection

Technical Specifications

• Package: The INA2180A4IDSGR comes in a VSSOP-10 package, which is compact and suitable for space-constrained applications.
• Temperature Range: It operates over an extended industrial temperature range, making it reliable in harsh environments.
• Supply Voltage: The device is designed to work with a supply voltage that caters to a wide array of industrial and automotive applications.

With its combination of dual-channel integration, high accuracy, and low power consumption, the INA2180A4IDSGR from Texas Instruments is a robust solution for current sensing in modern electronic systems.
