INA114AP

Name: INA114AP
Brand: Texas Instruments
SKU: 157331
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	INA114AP
Manufacturer	Texas Instruments
Catalog	Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description	IC OPAMP INSTR 1MHZ 8DIP
Datasheet	INA114AP Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Tube/Rail
Status	Active
Amplifier Type	Instrumentation
Number of Circuits	1
Slew Rate	0.6 V/μs
-3db Bandwidth	1MHz
Current - Input Bias	500pA
Voltage - Input Offset	25μV
Operating Supply Current	2.2mA
Channel Output Current	20mA
Supply Voltage - Operating	4.5 V to 36 V, ±2.25 V to 18 V
Temperature Range - Operating	-40°C to 85°C
Mounting	Through Hole
Case / Package	8-PDIP
Win Source Part Number	001747-INA114AP
Family Name	INA114
Introduction Date	January 01, 2006
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2028
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian INA114AP CAD Model

Alternative Products

Description

The INA114AP is a high-quality precision instrumentation amplifier produced by the globally renowned electronics manufacturer, Texas Instruments.

Offset Voltage: 50μV (max)
Gain: 1V/V (min)
Common-Mode Rejection Ratio (CMRR): 106dB @ G = 1
Gain Setting: Single external resistor sets gain from 1 to 10,000
Supply Range: ±2.25V to ±18V
Temperature Range: -40°C to 85°C
Package: 8-pin DIP
