DS8922AMX Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 70mV
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 090796-DS8922AMX
Family Name DS8922A
Introduction Date February 01, 1997
ECCN EAR99
Country of Origin Malaysia
Halogen Free Not Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian DS8922AMX CAD Model

Description

Product Overview

Engineered for high-speed, reliable communication, the DS8922AMX provides exceptional performance in a compact design. It is optimized for differential signaling applications and meets various standards for industrial and commercial usage.

Features and Benefits

  • Compact package design for space-constrained applications
  • High-speed operation up to 30 Mbps
  • Advanced noise immunity for stable data transmission
  • Designed to operate efficiently over a broad temperature range

Applications

  • Compact and portable communication equipment
  • Integrated automation systems
  • High-speed data links in constrained environments
