DAC7311IDCKR Texas Instruments DAC7311IDCKR Real Image DAC7311IDCKR real image DAC7311IDCKR label picture 2 DAC7311IDCKR real image 2 DAC7311IDCKR real image3195 DAC7311IDCKR real image3196 DAC7311IDCKR real image3197 DAC7311IDCKR real image3198 DAC7311IDCKR Real Image1 DAC7311IDCKR Real Image2 DAC7311IDCKR Real Image3 DAC7311IDCKR Real Image4 DAC7311IDCKR Real Image5 DAC7311IDCKR Real Image6
Same model may have multiple batches, images only for reference.
DAC7311IDCKR Texas Instruments DAC7311IDCKR Real Image DAC7311IDCKR real image DAC7311IDCKR label picture 2 DAC7311IDCKR real image 2 DAC7311IDCKR real image3195 DAC7311IDCKR real image3196 DAC7311IDCKR real image3197 DAC7311IDCKR real image3198 DAC7311IDCKR Real Image1 DAC7311IDCKR Real Image2 DAC7311IDCKR Real Image3 DAC7311IDCKR Real Image4 DAC7311IDCKR Real Image5 DAC7311IDCKR Real Image6
DAC7311IDCKR Texas Instruments DAC7311IDCKR Real Image DAC7311IDCKR real image DAC7311IDCKR label picture 2 DAC7311IDCKR real image 2 DAC7311IDCKR real image3195 DAC7311IDCKR real image3196 DAC7311IDCKR real image3197 DAC7311IDCKR real image3198 DAC7311IDCKR Real Image1 DAC7311IDCKR Real Image2 DAC7311IDCKR Real Image3 DAC7311IDCKR Real Image4 DAC7311IDCKR Real Image5 DAC7311IDCKR Real Image6
Same model may have multiple batches, images only for reference.

DAC7311IDCKR

Part No DAC7311IDCKR
Manufacturer Texas Instruments
Catalog Data Acquisition - Digital to Analog Converters (DAC)
Description IC DAC 12BIT 1CH LP SC70-6
Datasheet
DAC7311IDCKR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of Bits 12
Number of D/A Converters 1
Settling Time 12μs (Typ)
Output Type Voltage - Buffered
Differential Output No
Data Interface SPI, DSP
Reference Type Supply
Analog Supply Voltage 2 V to 5.5 V
Digital Supply Voltage 2 V to 5.5 V
INL/DNL (LSB) ±0.3, ±0.2
Temperature Range - Operating -40°C to 125°C
Case / Package SC-70-6
Win Source Part Number 013635-DAC7311IDCKR
Family Name DAC7311
Introduction Date May 01, 2008
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Automation & Process Control, Industrial, Automotive, Consumer Electronics, Sensing & Instrumentation
Ultra Librarian 3D Model Ultra Librarian DAC7311IDCKR CAD Model

Description

Product Overview

The DAC7311IDCKR is a single-channel, low-power DAC specifically tailored for small form-factor applications. It offers an excellent balance between performance and power efficiency.

Features and Benefits

  • Supply voltage: 2.7V to 5.5V for flexible power options
  • Integral nonlinearity error (INL) of 1 LSB max for superior linearity
  • Fast settling time to support dynamic signal outputs

Applications

  • Portable medical instruments
  • Battery-powered test equipment
  • Wireless and RF communication devices
