Products specifications

Categories RF/IF and RFID
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type TxRx + MCU
RF Family/Standard General ISM
Modulation 2FSK, 2GFSK, 4FSK, 4GFSK, MSK, OOK
Frequency 164MHz to 192MHz, 274MHz to 320MHz, 410MHz to 480MHz, 820MHz to 960MHz
Data Rate (Max) 200kbps
Power - Output 16dBm
Sensitivity -129dBm
Memory Size 4kB ROM, 256B RAM
Serial Interfaces SPI
GPIO 4
Supply Voltage - Operating 2 V to 3.6 V
Current - Receiving 17mA to 27mA
Current - Transmitting 26mA to 56mA
Temperature Range - Operating -40°C to 85°C
Dimension 32-VFQFN Exposed Pad
Win Source Part Number 120196-CC1125RHBR
Popularity Medium
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian CC1125RHBR CAD Model

Description

The CC1125RHBR offers developers a robust RF transceiver solution that excels in environments requiring high reliability and long-range communication, boosting efficiency across various applications.

Features and Benefits

  • Extended range with high reception sensitivity.
  • Advanced interference protection functionalities.
  • Spectral capacity support for improved performance.
  • Highly configurable offering broad adaptability.

Applications

  • Public Safety Communication
  • High-reliability Alarm Systems
  • Disaster Recovery Communication Networks
  • Precision Agricultural Sensors

With the CC1125RHBR, developers are better equipped to design solutions that demand durability, range, and clarity, making it ideal for high-stakes communication environments.
